PVC Coated Galvanised Steel Wire Rope

Galvanised steel wire rope with a PVC outer coating, combining the strength of a steel cable core with a protective, non-abrasive plastic outer layer. It's built as a 6×7 FC (fibre core) construction to DIN 3055 - six strands of wire laid around a flexible fibre core - and is supplied across five diameters, from 3mm (0.12") up to 8mm (0.31"), in cut lengths from 1m up to 100m to suit anything from a single garden repair to a full continuous run. It's flexible, weatherproof and corrosion-resistant by design.

The fibre-core construction gives flexibility and easier handling, so this rope coils and routes around posts and fixings more readily than a stiffer steel-cored cable of the same diameter. Before coating, the steel core itself is galvanised for corrosion resistance, and the PVC outer layer then adds a further weatherproof barrier on top of that, along with a smoother, more comfortable handling surface than bare wire rope. The PVC layer also stops the cable scratching or marking any surface it rests against or is wrapped around, which matters as much for a washing line as it does for a garden feature in view of the house.

Each diameter is simply the steel core plus its PVC layer, and the two scale together as the rope gets larger: the 3mm, 4mm and 5mm ropes are all built on a 1mm PVC layer over a progressively thicker core, while the 6mm and 8mm ropes step up to a 2mm PVC layer over a thicker core again - so the larger the diameter, the thicker both the core and the coating, and the higher the working load the rope carries.

Key Features

• Galvanised steel wire core for corrosion resistance, with a PVC layer coated on afterwards for extra weather protection
• 6×7 FC (fibre core) construction to DIN 3055, built for flexibility and easier handling
• PVC coating gives a smoother, non-abrasive handling surface than bare wire rope and protects any surface the cable rests against or is wrapped around from scratching
• Five diameters available, from 3mm (0.12") up to 8mm (0.31"), so the rope can be matched to the size and weight of the job
• Larger diameters use both a thicker steel core and a thicker PVC layer, for proportionally higher working loads
• Supplied in cut lengths from 1m (3.3ft) up to 100m (328ft), covering everything from a short repair to a full reel-length run
• Flexible and weatherproof, with corrosion resistance built in from the galvanised core outwards

Specification

The steel core diameter and PVC coating thickness that make up each overall rope diameter:

• Core: Galvanised steel wire rope, 6×7 FC construction (DIN 3055)
• Outer layer: PVC coating

Available cut lengths:

Typical Applications

The combination of a flexible fibre-core rope and a weatherproof, non-abrasive PVC coating suits this cable to a wide range of outdoor and general-purpose jobs:

• Clotheslines and garden washing lines, where the PVC coating keeps washing clear of bare wire and copes with permanent outdoor exposure
• Securing and tying down loads for transport, storage or general site use
• Garden and outdoor rigging - trellis and plant supports, fencing wire runs and similar structures - where the flexible fibre-core construction makes the rope easier to route around posts and fixings than a stiffer alternative
• Lifting and securing construction elements on site
• General DIY and construction tie-down applications, with the diameter chosen to suit the size and weight of the job in hand

As a general guide, the smaller 3mm and 4mm diameters suit lighter-duty tasks such as clothesline and garden rigging work, while the 6mm and 8mm diameters, with their thicker steel core, suit the heavier tie-down and site work described above - matching the diameter to the job follows directly from the higher working load that the thicker core diameters carry.

Cutting & Handling

When cutting to length, seal or tape the cut ends first, before cutting through the PVC coating - this stops the strands underneath unravelling once the coating that holds them together is cut through. Cut cleanly with a proper wire rope cutter or an angle grinder rather than side cutters where possible, for a tidier, less frayed end on both the core and the coating.
